elevated人行天桥

elevated pedestrian crossing

https://3dsky.org/3dmodels/show/nadzemnyi_peshekhodnyi_perekhod

Platform: 3dsMax 2014 + fbx Render: Corona

Competitive work. Approximate model of the project bridge LAURENT SAINT VAL. Repeat exactly the particular goal did not stand, because the main idea was to try to adapt it to the urban moderately busy highways (as far as the span of this structure allows), such elements as a garden or an observation platform would hardly be appropriate in the general city turmoil. Although if you want it is easy to fix. The model is partially under smoothing (you can not use it, but in order to avoid unnecessary angularities, it is better to use a modifier). These objects have the prefix "turbo". Smoothing is performed by the method of "smoothing groups", so put the appropriate checkbox in the turbosmooth modifier. And when importing an FBX file, we also tick off the import point for smoothing groups. A simplified material was created for exporting to the FBX file, since Because of the composite materials, errors could have occurred when importing into a new scene. Therefore, when opening FBX in a new scene, we immediately add the full material. The full material file and all textures naturally lie next to the model in the archive. If necessary, you may have to tweak the paths to the textures through Asset Tracking.
